If the printing position and the cutting position are offset as shown in the figure below, you can correct the issue by adjusting either the printing position or the cutting position. This example shows the procedure for adjusting the cutting position.

CROP - L/W Values

Input range: - 25 mm to 25 mm

To move the cutting line 0.5 mm to the left → Enter the W value



To move the cutting line 0.5 mm down → Enter the L value



To move the cutting line 0.7mm up and 0.5 mm to the right → Enter both W and L values



1. Set the CROP - L value

Make sure that the material is load to the machine.
  1. Press several times to display the screen shown in the figure.



  2. Press several times.



  3. Press .



  4. Press several times to display the screen shown in the figure.

  5. Press twice.

    The screen below is displayed. First enter the CROP - L value.

  6. Press to enter the values.

    Refer to the section above titled "CROP - L/W Values" to enter the values.



  7. Press .

    The screen below is displayed.



  1. 2. Set the CROP - W value

  2. Press .

    The screen below is displayed. Enter the CROP - W value.

  3. Press .



  4. Press to enter the values.



  5. Press .

    When you have finished, press the key to go back to the screen in the figure.

  6. Send cutting data.

    Perform cutting again and check the cutting position.
